Features:
Supports Both Wi-Fi and Wired Mode.
Support Micro SD card,up to 64G.
Support for mobile video surveillance(iOS,android) : Yoosee
Support Motion D etection & Email Alert.
1080P/960P/720P Optional,Max 30fps.
Support ONVIF protocol, work with third part NVR.
Specifications:
Video Compression : H.264
Video Resolution : 1920*1080P/1280*960P/1280*720P
Support frame rate from 1 to 30 frames/sec adjustable
Lens :2.8mm default
IR Cut Filter : Yes
Wireless : wifi 802.11b/g/n
Motion Detect & Email Alert: Supports
Connector: 1PCS LAN Port/1PCS Power Connector/1PCS Reset Button
Mobile Monitoring : Support IOS & Android With APP Yoosee
IR LED : 24pcs IR LED With 25Meters IR Distance
Woring Temperature : -20 to 60℃
Power : 12V 1A to 2A
SD Card Slot : Max 64Gb (NOT Included)
Important Notice:
1. Support ONVIF protocol, work with third part NVR (Recently it doesn't support view on Onvif Device Manager since the compatible issue.)
2. To install the Micro SD card, need to open the camera, find out the S D card slot on back of the camera board, contact us for instruction if you have any problem to fix it.
3.This cameras NOT supports Website Interface such as IE, Chrome.
4.The recording time depends on the SD Card you install, check below recording time for reference: 8Gb: 2days, 16Gb: 4-5days, 32Gb:8-10days. 64Gb:18-20days
FAQ:
Q1: How about the Network Function .does it support WiFi ?
A1: This camera can only work with 2.4GHz Wifi network, so please check your wifi network before placing order.
The WiFi distance depends on signal strength of your Wifi network. Please modify your wifi network name if it's very long or with some symbols, as it may cause the camera connection failure.
If your Wifi network is not 2.4GHz, Please connect the camera to your router through LAN cable.
A2: If you failed to use the smartlink to connect your camera to your WiFi.
Please try to connect your camera to your router through Lan cable, then set 'Network settings' – 'WiFi'. choose your WiFi network and input WiFi password;
Q2: I need safety and also my families. Does it provide alarm for us?
A1: This camera with motion d etection function.It can Buzzer/pop alarm message/push email when detect motion action.
Q3: I care about Real time video review of the camera. is it HD and clear? Is it useful at night?
A1: You can review the live video through iPhone/Android mobile phones/Windows PC .
A2: The camera work day & night. The video is color in daytime, black & white at night.
A3: The camera support desk/wall/ceilling installation. You can reverse the image according your installation way. Video formwat support PAL and NTSC.
Q4: I hope I can record with this camera. Do I need a memory card? how dose it work?
A1: Before recording. You need insert a memory card. it support 64Gb MAX .
A2: The record need about 2Gb/day. it means you need a 64Gb memory card if you want to record for a month. And you it support circle recording
A3: It supports 3 record mode: Manual Recording/Alarm Recording/Scheduled Recording .
Manual Recording : the recording will start/stop according you turn on/off the record switch.
Alarm Recording : the recording will start once the alarm is triggered,and you can set record 1/2/3 minutes.
Scheduled Recording :you can set a time period that record.
A4: It record on SD mode .and auto circulate record is available. Every video file is 30 minutes max (about 250 Mb).
it support a memory card 64Gb MAX .Please format your memory card at your first time recording.
A5: The video record can playback directly on your mobile APP.
Q5: I don't want hacker view my camera .I need Safety. Will it work?
A1: The default password is 123. For your security, please modify your camera password as soon as you connect your camera to your network.
A2: If someone want to connect your camera but you don't want to give more permission to him.you can set a Guest Password . he can just view and talk through camera and can't set it .
Packing Included:
1 x 720p/960p /1080p WIFI Camera
1 x User Manual
Detail Pictures:
